Материнская плата Acer D1F-AD V:1.0 15-Y32-011000 для настольного компьютера Desktop Acer Aspire X1430, X1430G. Процессор AMD E-450, без радиатора. Протестирована. Отправляем в регионы.

Chipset

AMD A45 Fusion

Integrated Graphics

AMD Radeon HD 6310

Memory

2 x 240-pin DDR3 DIMM slots Supports Dual Channel DDR3 1333/1066 MHz non-ECC, un-buffered memory. (8GB Max)

Expansion Slots

1 x PCI Express x1

1 x PCI Express (2.0) x16

Storage

2 x SATAII 3Gb/s connectors

- Supports HDDs, Internal Solid State Drive (SSD)

Audio

Realtek – High Definition

Ethernet

Realtek – (Gigabit)

Rear Panel

1 x PS/2 port for keyboard (purple color)

1 x PS/2 port for mouse (green color)

1 x VGA port

1 x HDMI port

1 x Audio I/O

1 x RJ45 LAN port !!!НЕ РАБОТАЕТ!!!

4 x USB 2.0 ports

Internal

1 x USB header

1 x 3-pin CPU Fan connector

1 x 24-pin ATX Power connector

1 x Front Panel header

1 x Front Audio header

1 x Clear CMOS jumper

1 x Battery socket (3V)

BIOS

Form Factor

Micro-ATX
