Lenovo Thinkstation C30 03T8422 Intel LGA 2011_Socket R

новое с процессорами e5-2609 2 шт и установленными радиаторами

Motherboard – C30 Table 1. C30 Motherboard Summary C30 Motherboard Summary Form Factor Board Size 12.23″ x 14.01″ (310.68mm x 355.9mm) Layout Custom, based on Extended‐ATX/EEB Standard Motherboard Core Processor Support Intel® Xeon™ Dual Core (Sandy Bridge EP) Intel® Xeon™ Quad Core Intel® Xeon™ Six Core Intel® Xeon™ Eight Core Intel® Xeon™ Ten Core Intel® Xeon™ Twelve Core Socket Type (2) x Intel Socket‐R (LGA2011) Memory Support 1866/1600/1333/1066/800 MHz QPI (GTPS) 6.4/7.2/8.0 GTPS Links Voltage Regulator VR12.1 – 130W TDP Chipset (PCH) Patsburg‐A (Intel C602) Support for Intel HW module to allow enablement of Patsburg‐B Flash 128Mbit SPI Flash with FWH HW Monitor N/A Super I/O Nuvoton 6681D Clock ICS932SQ420B Audio Realtek ALC662‐VD Ethernet Intel Lewisville(82579) SAS Integrated with Patsburg –A + Enablement Module (Patsburg –B equivalent) Memory Slots 4 per CPU socket Channels 4 per CPU socket Type DDR3 Unbuffered SDRAM (UDIMM, RDIMM, LRDIMM) ECC Support Yes Speed Up to PC3‐14900 (1866MHz) Max DIMM Size Up to 8GB UDIMM, up to 32GB RDIMM Max System Memory UDIMM: up to 64GB (w/8GB modules) RDIMM: up to 256GB RDIMM (w/32GB modules) Ethernet Vendor Intel Count 1 EEPROM None (part of SPI flash) Speeds 10/100/1000 Mbps Functions PXE, WOL, AMT (82579), NC‐SI (82574), Jumbo Frames, Teaming Connectors (1) x RJ45 on Rear I/O 8/31/2017 Thinkstation-specs » ThinkStation C30 http://thinkstation-specs.com/thinkstation-c30/ 3/24 Audio Vendor Realtek Type HD (5.1) Internal Speaker Yes, using SSM2211 amplifier Connectors (3) x Rear 3.5mm Jacks (Line In, Line Out, Microphone In) (2) x Front 3.5mm Jacks (Headphone out, Microphone In) (1) x 2‐Pin Internal Speaker Header Video Onboard Adapter (2) x PCI‐E 3.0 16‐Lane Slots Additional adapters may be supported in x4 slots for Spec Bids Multi‐GPU Support BIOS supported, card dependent Storage Floppy None IDE None SATA/SAS (2) x SATA Connectors, Gen. 2 (AHCI) (2) x SATA Connectors, Gen. 3 (AHCI) (3) x SATA/SAS Connectors, Gen. 2 (SCU) (1) x eSATA Connector, Gen. 2 (eSATA bracket) • SATA RAID 0,1, 5 supported natively • SAS RAID 0,1 and SATA RAID 0,1 supported via SAS Enablement Module • SAS RAID 0,1,5 and SATA RAID 0,1,5 supported via LSI 9260‐8i adapter SAS RAID 0,1 5 and SATA RAID 0,1, 5 supported via LSI 9240‐8i adapter (with RAID5 key) eSATA (1) x eSATA Connector, Gen. 2, cabled to Slot via bracket Slots Slot 1 (Near CPU) 4‐Lane PCI‐E v3.0 (16‐Lane Mechanical) – Half Length, Full Height Slot 2 16‐Lane PCI‐E v3.0 – Full Length, Full Height Slot 3 PCI v2.3 – Full Length, Full Height Slot 4 16‐Lane PCI‐E v3.0 – Full Length, Full Height Slot 5 4‐Lane PCI‐E v2.0 Full Length, Full Height, open tailgate (RF 2.5) Slot 6 (Near Edge) PCI v2.3 – Half Length, Full Height Rear I/O COM (1) x Serial Port (COM1) eSATA (1) x eSATA Port (Gen. 2), optional via bracket LPT None Video Audio Microphone‐In, Line In, Line Out Ethernet (1) x RJ45 USB 2.0 (2) x USB 2.0 Ports USB 3.0 (2) x USB 3.0 Ports Firewire None Internal I/O USB 2.0 x Front Panel USB Header (2 ports, Base MTM) x Media Card Reader Header x Internal USB connector USB 3.0 x Front Panel USB 3.0 edge connector (2 ports) PS/2 (1) x 2‐port PS/2 Header (Rear) Audio (1) x Front Panel Mic & Line‐Out Header COM2 None Clear CMOS 3‐Pin Clear CMOS Header Speaker 2‐Pin Internal Speaker Header Chassis Intrusion 2‐Pin Chassis Intrusion Switch Header Firewire None 8/31/2017 Thinkstation-specs » ThinkStation C30 http://thinkstation-specs.com/thinkstation-c30/ 4/24 Thermal Fans (1) x 4‐Wire CPU Fans (1) x 5‐Wire Rear Fans (1 header, two fans) (1) x 4‐Wire Front Fan (2) x 5‐Wire Memory Fan (not used on C30) (1) x 3‐Wire PCH Fan (PCH fan not installed) Power Connectors Main (1) 24‐Pin (2×12) ATX Standard Memory & CPU (2) 8‐Pin (2×4) ATX 12V Standard Graphics (1) 4‐Pin (2×2) ATX 12V Standard Security TPM Version 1.2, Nuvoton NPCT421LA0WX (Base MTMs) Version 1.2, ST Micro ST33TPM12LPC (MTMs and later) Asset ID NXP PCA24S08 vPro AMT 8.0 BIOS Vendor AMI Ethernet The C30 motherboard implements an onboard gigabit Ethernet port via the Intel (82579) PHY. This integrated solution has support for the industry standard functions of Wake on LAN (WOL) and Preboot Execution Environment (PXE), Teaming, and Jumbo Frames. Additionally, for Manageability features, (82579) will support AMT 7.0. Audio The ALC662‐VD chip from Realtek provides C30 with stereo audio capability that meets Windows7 Premium performance requirements. There are 2 front analog jacks, and 3 rear color‐coded analog jacks. Clock Generator The clock generator chip on C30 is an ICS932SQ420B. It is compliant with the Intel requirement for CK420 clock generation, and had downstream support with a DB1900Z clock buffer. Chassis Summary Chassis Info Chassis Format: Tower Chassis Dimension – cm: 444mm D x 130mm W x 427mm H Chassis Dimension – in: 17.48″ D x 5.12″ W x 16.81″ H Chassis Weight = 40.7 lbs (18.5kg) maximum configuration Chassis color: Raven Black Power supply: 800W 90% Efficient 2P Thermal Solutions A single unique heatsink design for the front CPU (CPU1) that supports up to 135W processors. The rear CPU (CPU2) heatsink design is common with S30 and D30, and also support up to 135W CPUs. Security & Serviceability Physical Security and Serviceability Access Panel Tool‐less side cover removal Optical Drive Tool‐less Hard Drives Tool‐less Expansion Cards Tool‐less Processor Socket Tool‐less Color coded User Touch Points Yes Color‐coordinated Cables and Connectors Yes Memory Tool‐
