Продам контроллер ЧПУ 4-х осевой на Toshiba TB6560AHQ в алюминиевом корпусе. ток до 3,5А
Продан по цене «Купить сейчас».
20 фев 2015 07:57
Этот лот уже не продается, но мы нашли для вас похожие
Продам контроллер ЧПУ 4-х осевой на Toshiba TB6560AHQ в алюминиевом к...
Текущая цена
3 300 руб.
Блиц-цена
3 300 руб.
Текущая цена
3 300 руб.
Победитель
1
Блиц-цена
3 300 руб.
Продан по Блиц-цене(20 фев 2015 07:57)
1 человек минимальное кол-во участников торгов
Описание
Состояние | Новое |
Интерфейс | Другой |
Комплектующее для | Универсальное |
Состояние нового, использовался один раз для проверки и настройки. в наличии.
Product Features:
Adopt Original Toshiba TB6560AHQ chip - High power, maximum 3.5A drive current chipset!
Click here For TB6560AHQ Datasheet.
Adjustable "0.5A-3.5A(Peak Current)" Drive Current Settings: the ouput current of actual operation on each axis can be set to "20%, 50%, 75%, 100%" of the Maximum Current.
Adjustable Subdivision(Micro Step) Settings: 1, 1/2, 1/8, 1/16.
Adjustable Decay Mode Settings(4 modes):
I. 0% -- No Decay Mode;
II. 25% -- Slow Decay Mode;
III. 50% -- Mid Decay Mode;
IV. 100% -- Fast Decay Mode.
Automatic Semi-flow Control Function: adjustable semi-flow mode and adjustable semi-flow current , with multiple semi-flow model and semi-flow current settings.
With New-type Bipolar constant current chopping technology: High working precision, Low vibration, Low noise.
Professional design with super anti-jamming function for steadier running.
Overload, Overheat Protection Function: Protect the computer, driver board and other equipments from being damaged.
Cooling Aluminium box Design: Cooling function and pprotect the driver board from being damaged by dirt, dust or other liquids.
Full closed-type optical isolation(Formal Photoelectric Coupler) to protect the user's computer and equipment
Standard parallel interface, supports software MACH2, MACH3(recommended), EMC2, KCAM4 etc..
(*For compatibility with other softwares, please feel free to contact us.)
отдам за 4300р.
Product Features:
Adopt Original Toshiba TB6560AHQ chip - High power, maximum 3.5A drive current chipset!
Click here For TB6560AHQ Datasheet.
Adjustable "0.5A-3.5A(Peak Current)" Drive Current Settings: the ouput current of actual operation on each axis can be set to "20%, 50%, 75%, 100%" of the Maximum Current.
Adjustable Subdivision(Micro Step) Settings: 1, 1/2, 1/8, 1/16.
Adjustable Decay Mode Settings(4 modes):
I. 0% -- No Decay Mode;
II. 25% -- Slow Decay Mode;
III. 50% -- Mid Decay Mode;
IV. 100% -- Fast Decay Mode.
Automatic Semi-flow Control Function: adjustable semi-flow mode and adjustable semi-flow current , with multiple semi-flow model and semi-flow current settings.
With New-type Bipolar constant current chopping technology: High working precision, Low vibration, Low noise.
Professional design with super anti-jamming function for steadier running.
Overload, Overheat Protection Function: Protect the computer, driver board and other equipments from being damaged.
Cooling Aluminium box Design: Cooling function and pprotect the driver board from being damaged by dirt, dust or other liquids.
Full closed-type optical isolation(Formal Photoelectric Coupler) to protect the user's computer and equipment
Standard parallel interface, supports software MACH2, MACH3(recommended), EMC2, KCAM4 etc..
(*For compatibility with other softwares, please feel free to contact us.)
отдам за 4300р.
