The Quadro FX 4500 SDI was a professional graphics card by NVIDIA, launched on January 30th, 2006. Built on the 110 nm process, and based on the G70 graphics processor, the card supports DirectX 9.0c. Since Quadro FX 4500 SDI does not support DirectX 11 or DirectX 12, it might not be able to run all the latest games. The G70 graphics processor is a large chip with a die area of 333 mm² and 302 million transistors. It features 24 pixel shaders and 8 vertex shaders, 24 texture mapping units, and 16 ROPs. Due to the lack of unified shaders you will not be able to run recent games at all (which require unified shader/DX10+ support). NVIDIA has paired 512 MB GDDR3 memory with the Quadro FX 4500 SDI, which are connected using a 256-bit memory interface. The GPU is operating at a frequency of 430 MHz, memory is running at 525 MHz.

Being a triple-slot card, the NVIDIA Quadro FX 4500 SDI draws power from 1x 6-pin power connector, with power draw rated at 116 W maximum. Display outputs include: 2x DVI, 1x S-Video. Quadro FX 4500 SDI is connected to the rest of the system using a PCI-Express 1.0 x16 interface. The card measures 267 mm in length, 111 mm in width, and features a triple-slot cooling solution.
